Basic Definition
OPT is short for Optimization, and an optimization problem is defined as follow:
where $f: \mathbb{R}^n \to \mathbb{R}$ is called the objective function (决策函数), $x$ is the decision variable (决策变量), and $X$ is the feasible region (可行域) . Moreover, $min$ for minimize and $s.t.$ for subject to.
$x^*$ is an optimal solution of 1 iff. $ \space x^* \in X, f(x^*)\leq f(x), \forall x\in X$ where $f(x^*)$ is the optimal value of 1.
Some special cases:
- infeasible(不可行): $X = \emptyset$;
- unbounded(无界):$(x^n)_{n=1}^{\infin}\in X$, $f(x^n)\to \infty$;
- not achieved(无法取得): not exist $ x^* \in X $, so that $ f(x^*)=inf{f(x)|x\in X} $
$\bar{x}$ is a local minimum(局部极小值点) of function $f$, if there exists $\delta>0$ such that
$$f(\bar{x})\leq f(x), \forall x\in X, ||x-\bar{x}||_2<\delta$$$\bar{x}$ is a strict local minimum of function $f$, if there exists $\delta>0$ such that
$$f(\bar{x})< f(x), \forall x\in X, ||x-\bar{x}||_2<\delta\space and\space x\neq \bar{x}$$Mathematical Foundations
Linear Algebra
The space $\mathbb{R}^n$
A vector (or point) $x$ in $\mathbb{R}^n$ is an ordered collection of $n$ real numbers, which can be given as $x=(x_1,x_2,x_3,\cdots,x_n)$.
scalar multiplication(数乘) $a\in \mathbb{R}, x \in \mathbb{R}^n, ax=(ax_1,ax_2,\cdots,ax_n)$
addition(向量加法) $x\in\mathbb{R}^n, y\in\mathbb{R}^n, x+y=(x_1+y_1,x_2+y_2,\cdots,x_n+y_n)$
linear subspace(线性子空间) A nonempty subset $S$ of $\mathbb{R}^n$ is a linear subspace iff.
$$ x,y\in S, x+y\in S;x\in S,a\in \mathbb{R},ax\in S $$(对加法和数乘封闭)
linear combinations(线性组合) & span(线性生成空间)
$$ \mathcal{V}=\{v_1,v_2,\cdots,v_m\}\in \mathbb{R}^n, a_1,a_2,\cdots,a_m\in\mathbb{R} $$$\sum_{i=1}^ma_iv_i$ is a linear combination;
$$ span(\mathcal{V}):=\{ a_1v_1+a_2v_2+\cdots+a_mv_m \mid a_1,a_2,\cdots,a_m\in\mathbb{R} \} $$linear independent(线性无关) & linear dependent(线性相关)
linear independent: $v=a_1v_1+a_2v_2+\cdots+a_mv_m=\mathbf{0}$ iff. $a_1=a_2=\cdots=a_m=0$
linear dependent: exists a non-zero ${a_k}$, such that $v=\mathbf{0}$.
Basis(基)
$\mathcal{V}$ is a basis of linear subspace $S$ of $\mathbb{R}^n$, if $span(\mathcal{V})=S$ and $\mathcal{V}$ is linear independent
Some useful facts:
- The span of $\mathcal{V}$ is a linear subspace of $\mathbb{R}^n$;
- $\mathcal{V}$ is linear independent if and only if every $v\in span(\mathcal{V})$ can be uniquely represented as a linear combination of $\mathcal{V}$;
- $\mathcal{V}$ is linear independent. If $v\notin span(\mathcal{V})$ the $\mathcal{V}\cup v$ is linear independent;
- If $\mathcal{V}$ is linear dependent, there exists a nonzero vector $v\in\mathcal{V}$ such that $v\in span(\mathcal{V\backslash v}), span(\mathcal{V})=span(\mathcal{V\backslash v})$.
(重复加入/减去线性无关向量直到构成基)
Let $L={v_1,v_2,…,v_k}$ be a linearly independent set of vectors in W. We want to find a set of vectors ${u_1,u_2,…,u_m}\subseteq \mathcal{V}$ such that the combined set $B=L∪{u_1,…,u_m}$ is a basis for $\mathcal{W}$ .
We proceed with the following algorithm:
Check if $L$ spans $\mathcal{W}$ .
- If $span(L)=\mathcal{W}$, then $L$ is a linearly independent spanning set, which means $L$ is already a basis for $\mathcal{W}$. The proof is complete.
If $L$ does not span $\mathcal{W}$ .
- If $span(L)\neq\mathcal{W} $, then there must exist at least one vector in $\mathcal{W}$ that is not in the span of $L$. Since $\mathcal{W}=span(\mathcal{V})$, there must be a vector $u_1∈\mathcal{V}$ such that $u_1\notin span(\mathcal{V})$.
- Let’s form a new set $L_1=L∪{u_1}={v_1,…,v_k,u_1}$. We claim this new set is also linearly independent.
- To prove this, consider the equation: $c_1v_1+c_2v_2+⋯+c_kv_k+d_1u_1=0$
- Case 1: If $d1\neq 0$, we could rearrange the equation to express u1 as a linear combination of the vectors in $L$: $u_1=−d_{11}(c_1v_1+⋯+c_kv_k)$ This would imply that $u1\in span(L)$, which contradicts our choice of u1.
- Case 2: Therefore, we must have $d_1=0$. The equation simplifies to: $c_1v_1+c_2v_2+⋯+c_kv_k=0$ Since $L$ is a linearly independent set, the only solution to this equation is $c_1=c_2=⋯+c_k=0$.
- Thus, the only solution is that all coefficients ($c_i$ and $d_1$) are zero. This proves that the set $L_1$ is linearly independent.
Repeat the process.
- We now repeat the procedure with $L_1$. If $span(L_1)=\mathcal{W}$, we have found our basis. If not, we find another vector $u_2\in V$ such that $u_2\notin span(L_1)$ and form the larger, linearly independent set $L_2=L_1∪{u_2}$.
Since W is spanned by a finite set V, it is a finite-dimensional space. Let $dim(\mathcal{W})=n$. Any linearly independent set in $\mathcal{W}$ can contain at most n vectors. Our process starts with a set of k vectors and adds one vector at a time, maintaining linear independence at each step. Therefore, the process is guaranteed to terminate in at most n−k steps, at which point we have a set $B$ that is linearly independent and spans $\mathcal{W}$. By definition, $B$ is a basis for $\mathcal{W}$ that contains the original set $L$.
□Let $\mathcal{V}={v_1,v_2,\cdots,v_m}$ be a set that spans $\mathcal{W}$, i.e., $\mathcal{W}=span(\mathcal{V})$. We want to find a subset $B\subseteq \mathcal{V}$ that is a basis for $\mathcal{W}$.
We can construct the basis $B$ using the following “sifting” algorithm:
- Initialize an empty set, $B=\empty$.
- Iterate through each vector $v_i$ in $\mathcal{V}$ for $i=1,\cdots,m$.
- For each $v_i$, check if it is a linear combination of the vectors already in $B$. That is, check if $v_i\in span(B)$.
- If NO, then $v_i$ is linearly independent of the vectors in $B$. Add $v_i$ to $B$.
- If YES, then vi is a redundant vector (it depends linearly on other vectors). Discard $v_i$.
The final set $B$ produced by this algorithm is a basis for $\mathcal{W}$. We must prove two properties: that $B$ is linearly independent and that it spans $\mathcal{W}$.
- Linear Independence: By construction, a vector is only added to $B$ if it is not in the span of the vectors already in $B$. This condition directly ensures that the resulting set $B$ is linearly independent. If $B={b_1,\cdots,b_k}$ were linearly dependent, then by the properties of linear dependence, some vector $b_j$ would be a linear combination of the preceding vectors, $b_j\in span({b_1,…,b_{j−1}})$. But this contradicts the very rule we used to add $b_j$ to the set. Therefore, $B$ must be linearly independent.
- Spanning Property: We need to show that $span(B)=span(\mathcal{V})$.
- Since $B\subseteq\mathcal{V}$, it is clear that $span(B)\subseteq span(V)$.
- To show $span(V)\subseteq span(B)$, we must show that every vector $v_i\in \mathcal{V}$ is in $span(B)$.
- If a vector $v_i$ was added to $B$, then $v_i∈B$, so it is trivially in $span(B)$.
- If a vector $v_i$ was discarded, it was because at the moment of its consideration, it was already a linear combination of the vectors in the current version of $B$. Since the final set $B$ contains all these vectors, it follows that $v_i\in span(B)$.
- Since every vector in the original spanning set $\mathcal{V}$ can be expressed as a linear combination of vectors in $B$, the span of $\mathcal{V}$ cannot be larger than the span of $B$. Thus, $span(\mathcal{V})\subseteq span(B)$.
Combining the two inclusions, we have $span(B)=span(\mathcal{V})=\mathcal{W}$.
Since $B$ is a linearly independent set that spans $\mathcal{W}$, it is a basis for $\mathcal{W}$.
□Euclidean inner product, Euclidean norm, orthogonal
- Euclidean inner product
Given two vectors $x, y \in \mathbb{R}^n$, their Euclidean inner product is defined as
- bi-linearity(双线性性): when $\bar{x}$ is a fixed vector in $\mathbb{R}^n$, the function $<\bar{x}, y>$ is linear in variable $y$; when $\bar{y}$ is a fixed vector in $\mathbb{R}^n$, the function $<x, \bar{y}>$ is linear in variable $x$;
- symmetry(对称性): $<x, y>=<y, x>, \forall x, y \in \mathbb{R}^n$;
- positive definiteness(正定性): $\forall x \in \mathbb{R}^n, <x, x>\geq 0$, and is zero iff. $x=\mathbf{0}$
A function $f: \mathbb{R}^n \to \mathbb{R}$ is linear if for every $ x,y \in \mathbb{R}^n $ and $ \alpha, \beta \in \mathbb{R} $,
$$ f(\alpha x+ \beta y)=\alpha f(x)+ \beta f(y) $$Let $<\cdot , \cdot>$ be the Euclidean inner product on $\mathbb{R}^n \to \mathbb{R}$.
- For every vector $a \in \mathbb{R}^n$, $<a,x>$ is a linear function from $ \mathbb{R}^n \to \mathbb{R} $,
- Let $f(x)$ be a linear function from $ \mathbb{R}^n \to \mathbb{R} $. Then, there exists a unique vector $a\in \mathbb{R}^n$ so that $f(x)=<a, x>$ for every $x\in \mathbb{R}^n$.
- Let $f(x)=<a, x>$, for every $x, y\in \mathbb{R}^n$ and $\alpha, \beta \in \mathbb{R}$ $$ \begin{align*} f(\alpha x+ \beta y) &= \langle a, \alpha x+ \beta y \rangle \\ &= \alpha \langle a, x \rangle + \beta \langle a, y \rangle \\ &= \alpha f(x) + \beta f(y) \end{align*} $$ $f(x)$ is a linear function;
- Let $f(x)$ be a linear function, $$ \begin{align*} f(x) &=f(\sum x_ie_i) \\ &=\sum x_if(e_i) \\ &=\langle a, x \rangle \end{align*} $$ in which $a=(f(e_1),\cdots,f(e_n))$.
Extending Theorem 2 from scalar-valued linear functions $f: \mathbb{R}^n \to \mathbb{R}$ to vector-valued linear functions $f: \mathbb{R}^n \to \mathbb{R}^m$, we derive the following corollary:
- Let $A$ be a $m \times n$ matrix whose row vectors are $a_1^T,\cdots,a_m^T$. Then, $Ax$ is a linear function from $\mathbb{R}^n \to \mathbb{R}^m$;
- Let $f(x)$ be a linear function from $\mathbb{R}^n \to \mathbb{R}^m$. Then there exists a unique $m \times n$ matrix $A$ such that $f(x)=Ax$.
- Euclidean norm
The Euclidean norm of $x\in \mathbb{R}^n$ is defined as
$$ ||x||_2=\sqrt{\langle x,x \rangle}=\sqrt{\sum_{i=1}^n x_i^2}. $$An important inequality: Cauchy-Schwarz inequality(柯西施瓦茨不等式)
$$ |\langle x,y \rangle|\leq||x||_2\cdot ||y||_2. $$- orthogonal(正交)
$x$ and $y$ are orthogonal iff. $<x,y>=0$.
Four fundamental subspaces
The column space of matrix $ A $, denoted $ Col(A) $, is the subspace spanned by the linear combinations of its column vectors.
$$ Col(A) = \{ A\mathbf{x} \mid \mathbf{x} \in \mathbb{R}^n \} $$where $ A $ is an $ m \times n $ matrix and $ \mathbf{x} $ is an $ n $-dimensional vector.
The row space of matrix $ A $, denoted $ \text{Row}(A) $, is the subspace spanned by the linear combinations of its row vectors.
$$ \text{Row}(A) = \{ \mathbf{y}^T A \mid \mathbf{y} \in \mathbb{R}^m \} $$Equivalently, it is the column space of $ A^T $ ($ \text{Col}(A^T) $).
The null space of matrix $ A $, denoted $ \text{Null}(A) $, is the set of all vectors $ \mathbf{x} $ such that $ A\mathbf{x} = \mathbf{0} $.
$$ \text{Null}(A) = \{ \mathbf{x} \in \mathbb{R}^n \mid A\mathbf{x} = \mathbf{0} \} $$The left null space of matrix $ A $, denoted $ \text{Null}(A^T) $, is the set of all vectors $ \mathbf{y} $ such that $ \mathbf{y}^T A = \mathbf{0} $.
$$ \text{Null}(A^T) = \{ \mathbf{y} \in \mathbb{R}^m \mid \mathbf{y}^T A = \mathbf{0} \} $$This is equivalent to the null space of $ A^T $.
- Orthogonality:
- The column space $ \text{Col}(A) $ is orthogonal to the left null space $ \text{Null}(A^T) $ (in $ \mathbb{R}^m $).
- The row space $ \text{Row}(A) $ is orthogonal to the null space $ \text{Null}(A) $ (in $ \mathbb{R}^n $).
- Dimension Relationships:
- $ \text{rank}(A) = \dim(\text{Col}(A)) = \dim(\text{Row}(A)) $
- $ \dim(\text{Null}(A)) = n - \text{rank}(A) $
- $ \dim(\text{Null}(A^T)) = m - \text{rank}(A) $
